Boring Machine

Bores large holes and sizes cylinders to precision - the machine a cast cylinder blank passes through on its way to an engine. The window loads stock and swaps the cutter; holding the bed cell moves it under the tool. The boring process is not built yet.

Bores large holes and sizes cylinders to precision - the Boring Machine is the station a turned cylinder passes through on its way to an engine. The window cell loads the blank and swaps the cutter; holding the bed cell moves it under the tool.

Boring Machine, isometric
Boring Machine, from the northnorthBoring Machine, from the easteastBoring Machine, from the southsouthBoring Machine, from the westwestBoring Machine, the top (up)top
Boring Machine, isometric.
