Shaping Machine

Cuts small flat shapes from blanks and stock - dies, keys, small brackets - with a reciprocating ram. The window loads stock and swaps the cutter. The shaping process is not built yet.

Cuts small flat shapes from blanks and stock - dies, keys, small brackets - with a reciprocating ram rather than a rotating cutter. The window cell is where stock goes in and where the cutter is swapped.

Shaping Machine, isometric
Shaping Machine, from the northnorthShaping Machine, from the easteastShaping Machine, from the southsouthShaping Machine, from the westwestShaping Machine, the top (up)top
Shaping Machine, isometric.
