Coke oven

Coke oven, cutaway
Coke oven, layer 0Coke oven, layer +1Coke oven, layer +2Coke oven, layer +3Coke oven, layer +4
Seen from the south-east; the front faces south; north is up in the plans.
#ColourNameMatches
1Fireclay bricksgame:claybricks-good-fire
2Empty (air, or a pile of coal, or a charge Pile)*:@(air|coalpile|furnace-chargepile)
3Fireclay brick slabgame:brickslabs-fire-up-free
4Fireclay brick slabgame:brickslabs-fire-south-free
5Coke Oven Coreiiex:furnace-cokeovencore-*
6Coke Oven Dooriiex:furnace-cokechargedoor-n
7Charge Lidiiex:furnace-chargelid-n
8Top Hopperiiex:hopper-top-fire
9Reserved space (kept clear)exlib:structurefiller
10Empty (air)game:air

Materials

BlockCells
Fireclay bricks59
Fireclay brick slab9
Coke Oven Core1
Coke Oven Door1
Charge Lid1
Top Hopper1

Facings and connectors

  • Fireclay brick slab turns with the structure; segment 3 of its code names the face.
  • Coke Oven Door turns with the structure; segment 3 of its code names the face.
  • Charge Lid turns with the structure; segment 3 of its code names the face.

What it does

The coke oven is where coal becomes furnace charge. A shaft furnace burns only what carries the fuel role, which is coke and charcoal and no raw coal at any rank, and coke carries twice charcoal's carbon per unit. Every heat the blast furnace and the cupola pour is therefore waiting on this building.

It is one chamber in its own walls, in ordinary fire brick. The oven stands 5 cells wide, 5 deep and 5 tall; the chamber is three cells by three and holds 288 coal, which bakes into 216 coke. Build it before anything it feeds.

The coke oven, shown opening, isoThe coke oven, shown opening, open cycle
The coke oven, shown opening

Building it

  1. Place the core first. It sits at floor level in the middle of the first layer, under the chamber's centre cell, walled in.
  2. Ctrl plus shift plus right-click it for the build outline and the shopping list.
  3. Lay the floor and the chamber box, leaving the three-by-three cells open.
  4. Set a Coke Oven Door in the front wall, in the middle column of the chamber.
  5. Arch the crown over the chamber, leaving the cell over its centre open, lay the roof over it with a top hopper in the roof above that cell, and set a charge lid on the roof over the hopper.
  6. Keep laying until the outline reports complete.

The shell takes 59 fire brick blocks, 8 fire brick slabs for the crown and 1 more for the door's shoulder. Beside them you need one each of the Coke Oven Core, the Top Hopper, the Charge Lid and the Coke Oven Door.

The core's side variant fixes the facing and the whole oven turns with it. The chamber is derived from the layout rather than declared, so it follows whatever the drawing says.

Charging

Coal goes in from above, through the Top Hopper in the roof. Climb onto the oven, open the Charge Lid with a right-click, and right-click it again with bituminous coal in your hand. One click pours in one coal; ctrl plus right-click pours in the whole stack. The hopper holds 128 coal and lets it fall 8 a second, always onto the lowest part of the chamber, so the chamber fills level.

The chamber takes 288 coal, which is three loads of the hopper. You cannot charge it by hand: coal held to the chamber through the open door does nothing.

The oven takes bituminous coal and nothing else. Charcoal and coke are not coal, anthracite does not coke, and lignite is refused.

Sealing and lighting

Shut the lid and the door. Coke is made by baking coal away from the air, so the chamber's clock only runs while both are shut.

The oven lights only when the chamber is completely full, all 288 coal. With the lid open you can look into the hopper and read how much is in: Shaft: 288 / 288 units charged.

To light it, hold a flame to the lower half of the Coke Oven Door for a second and a half: a lit torch with shift and right-click, or a firestarter with right-click.

The run

  1. Open the lid and pour in 288 bituminous coal.
  2. Shut the lid and the door.
  3. Light the oven at the door.
  4. Wait. The oven takes 2.5 game hours to come up to heat and then bakes for 12, so the coke is ready 14.5 game hours after lighting. That is 29 real minutes at the default day, and sleeping passes it.
  5. Open the door and dig the coke out with a shovel. Each dig lifts 2 coke off the pile you aim at, so a full chamber is 108 digs.
  6. Dig out everything before charging again. Coke left in the chamber takes the room of the next charge.

Coke while one oven bakes takes a second oven. Opening the lid or the door during the bake pauses it, and shutting them carries on from where it stopped.

The chamber's progress shows on the core, and the core sits walled in under the chamber. To read it, dig a pit under the oven and look up at the core from below. Otherwise count the hours and open the door: a dig that gives coke means the bake is done.

If the oven is still hotter than 600 C when the chamber fills again, it catches from its own heat and needs no flame.

What goes wrong

The flame will not take at the door. The chamber is not completely full, or the oven is not finished. Nothing tells you which at the door. Pour in coal until the hopper reads 288 / 288, and ctrl plus shift plus right-click the door to bring back the build outline and see what is missing. The flame also has to be on the lower half of the door: the upper half and the lever post do not light.

The oven is lit but makes no coke. The lid or the door is open, or one of them is missing. The clock holds until both are shut, and the core reads "Standing open".

The bake lost its time. Taking the last of the coal out of the chamber sets its clock back to zero. The next charge bakes the full 12 hours.

A wall block was knocked out during a bake. The fire keeps burning but the clock stops, and the core reads "Structure is incomplete!". Put the block back and the bake carries on from where it stopped. If the fire goes out while the wall is open, the oven cannot be lit again until the wall is whole.

The fire went out. Drawing a lit oven below half full, 144 units, puts it out within a quarter of a game hour. The charge stays where it is. A chamber already part baked carries on while the oven stays above 400 C, and the oven loses 120 C a game hour. A chamber whose clock has not started waits. Fill the chamber to the top and light the door again; the 2.5 hours of heating up start over.

The core was broken. Everything in the chamber falls out as loose stacks of coal and coke, and the bake is lost. Pick it up, set a new core in the same place, and charge the oven again.
